True | 78" Wide 3 Sliding Door Bottom Mount Reach-In Refrigerator

Description

Reach-In Glass Slide Door Refrigerator with Hydrocarbon Refrigerant and LED Lighting

Designed using the highest quality materials and components to provide the user with colder product temperatures, lower utility costs, exceptional food safety and the best value in today’s food service marketplace. Sistema de refrigeración sobredimensionado y balanceado que mantiene una temperatura de 33ºF a 38ºF .5ºC a 3.3ºC (33°F a 38°F) lo mejor para la mejor preservación de alimentos. Factory engineered, self-contained, capillary tube system using environmentally friendly R290 hydro carbon refrigerant that has zero (0) ozone depletion potential (ODP), & 0.02 global warming potential (GWP). Stainless steel front. The very finest stainless with higher tensile strength for fewer dents and scratches. Energy efficient, “Low-E”, double pane thermal glass doors. Adjustable, heavy duty PVC coated shelves. NSF/ANSI Standard 7 compliant for open food product. Unique space saving design for space tight kitchens. LED interior lighting provides more even lighting throughout the cabinet. Safety shielded.

Features

• Exterior temperature display.
• Evaporator is epoxy coated to eliminate the potential of corrosion.
• NSF/ANSI Standard 7 compliant for open food product.

Warranty

7 Years - Labor / 7 Years - Parts / 7 Years- Compressor

Shipping

When you place an order, we will estimate shipping and delivery dates for you based on the availability of your items and the shipping options.

You can view our shipping policy here.

Returns/Refunds/Damages

Customers have 48 hours to inspect and report damages & no item may be returned after 30 days of the original ship date from our facilities. Items that are returned damaged or without proper packaging materials are subject up to a 25% restock fee.

You can view our return policy here.

Product Specifications

MODEL	TSD-69G-HC-LD
DOOR COUNT	3
SHELF COUNT	9
WEIGHT (LBS)	630
WEIGHT (KG)	286

Dimensions	Imperial	Metric
WIDTH	78–1/8	1985
DEPTH	29–5/8	753
HEIGHT	78–3/8	1991
HEIGHT	10	3.05

Electrical
AMPS	7.1
VOLTAGE	115/60/1
NEMA CONFIGURATION	19

Design

• True’s sliding door reach-in’s are designed with enduring quality that protects your long term investment.
• True’s commitment to using the highest quality materials and oversized refrigeration systems provides the user with colder product temperatures, lower utility costs, exceptional food safety and the best value in today’s food service marketplace.

Refrigeration System

• Factory engineered, self-contained, capillary tube system using environmentally friendly R290 hydrocarbon refrigerant that has zero (0) ozone depletion potential (ODP), & 0.02 global warming potential (GWP).
• Extra large evaporator coil balanced with higher horsepower compressor and large condenser; maintains 33°F to 38°F (.5°C to 3.3°C) for the best in food preservation.
• Sealed, self-lubricating evaporator fan motors and larger fan blades give True reach-in’s a more efficient, low velocity, high volume airflow design. This unique design ensures faster temperature recovery and shorter run times in the busiest of food service environments.
• Bottom mounted condensing unit positioned for easy maintenance. Compressor runs in coolest and most grease free area of the kitchen. Allows for storage area on top of unit.

Cabinet Construction

• Exterior - Stainless steel front. Anodized quality aluminum ends. Corrosion resistant GalFan coated steel back.
• Interior - attractive, clear coated aluminum liner. Stainless steel floor with coved corners.
• Insulation - entire cabinet structure is foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
• Welded, heavy duty steel frame rail, black powder coated for corrosion protection.
• Frame rail fitted with 6" (153 mm) legs.

Door

• “Low-E”, double pane thermal glass insert with mitered plastic channel frame.
• Each door fitted with 12" (305 mm) long molded plastic handle.
• Self-closing doors, efficient counter balanced weight system for smooth, even, positive closure. Sliding doors ride on stainless steel V-Channel with stainless steel bearings. Doors fit within plastic channel frame.

Shelving

• Nine (9) adjustable, heavy duty PVC coated wire shelves 23–7/8"L x 20–9/16"D (607 mm x 621 mm). Four (4) chrome plated shelf clips included per shelf.
• Shelf support pilasters made of same material as cabinet interior; shelves are adjustable on1/2" (13 mm) increments.

Lighting

• LED interior lighting provides more even lighting throughout the cabinet. Safety shielded.

Electrical

• Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase - 15 amp dedicated outlet. Cord and plug set included.
• NEMA-5-15R

Documents

Spec Sheet
